Abstract
The short-course will introduce the audience to a small and multiband antenna technology based on replacing a complex and usually customized antenna design with an off-the-shelf, standardized, miniature component called antenna booster. Being surface-mount and chip-like in nature, the antenna booster fits seamlessly in an electronic printed circuit board the same way any other electronic component such an amplifier, filter or switch, to name a few, does. It can be assembled with a conventional pick-and-place machine, making the manufacture and design of the new generation of IoT/Mobile or wireless device simpler, faster and more effective.
The audience (from PhD students to researchers in the field) will be introduced to the theory behind designing an antenna booster, will be given practical examples, and will participate in a hands-on, practical application using Microwave Office circuit design software.
Course outline
The short course will be divided in two parts.
The first part will include a detailed presentation on the theory, regarding how to design small/multiband antenna systems with antenna boosters and matching networks. The importance of physics in understanding how the technology works will be emphasized and the related applications of the technology will be fully discussed.
The second part will provide a hand-on experience and each attendee will have the opportunity to put the theory into practice. Using Microwave Office, two examples starting from scratch will be fully detailed. The examples will include the design of an ISM antenna system on a wireless platform and a multiband design for 4G operation (824MHz-960MHz and 1710MHz-2690MHz). Both examples will use an antenna booster of only 86.4mm3.
Attendees should bring a laptop and will be given a temporary license of Microwave Office to practice multiband matching networks during the course.
PROGRAM
Part I: Theory (1h)
- Introduction
- Fundamentals
- Antenna boosters
- Matching network architectures
- Single band applications
- Multiband band applications
- Other architectures
- Reconfigurability
- MIMO
- Questions and answers
Brea2
Part II: Design with Electromagnetic (EM) Software –Microwave Office and AXIEM EM Simulator (2h)
- Design of a small antenna system at ISM (Industrial-Scientific-Medical)
- Design of a multiband antenna system at 4G (824MHz-960MHz and 1710MHz-2690MHz)
- Both designs will start from scratch: from the initial S-parameter of an antenna booster without a matching network, to the final design including the optimized matching network with an antenna booster
Final questions and answers
Conclusion
Note 1: To make the course more productive, it is recommended attendees bring a personal laptop, since access to Microwave Office will be provided for designing some the examples given in the course.
Note 2: Each attendee will receive antenna booster samples as the ones used in the short-course to test in their facilities. Also, PCBs with the full antenna system as the ones designed in the tutorial will be given under request.
